LENOVO

X1 Carbon

Intel Core Ultra 7 165UCPU (Score: 16.705)
Intel GraphicsGPU (Score: 3.205)
N/AVALUE SCORE
32 GBRAM
1 TBSTORAGE
14" DISPLAY
Best Price
N/A

Price History

Loading price history...

Technical Specifications

Design

  • Product typeLaptop
  • Product colourBlack
  • Form factorClamshell
  • Housing materialAluminium, Carbon fibre

Display

  • Display diagonal35.6 cm (14")
  • Display resolution1920 x 1200 pixels
  • TouchscreenYes
  • HD typeWUXGA
  • Panel typeIPS
  • LED backlightYes
  • Native aspect ratio16:10
  • Anti-glare screenYes
  • Display brightness400 cd/m²
  • RGB colour spacesRGB
  • Colour gamut100%
  • Maximum refresh rate60 Hz
  • Contrast ratio (typical)1000:1

Processor

  • Processor manufacturerIntel
  • Processor familyIntel Core Ultra 7
  • Processor generationIntel® Core™ Ultra (Series 1)
  • Processor model165U
  • Processor cores12
  • Processor boost frequency4.9 GHz
  • Performance cores2
  • Efficient cores8
  • Low Power Efficient-cores2
  • Performance-core Max Turbo Frequency4.9 GHz
  • Efficient-core Max Turbo Frequency3.8 GHz
  • Low Power Efficient-core Max Turbo Frequency2.1 GHz
  • Performance-core base frequency1.7 GHz
  • Efficient-core base frequency1.2 GHz
  • Low Power Efficient-core Base Frequency700 MHz
  • Processor cache12 MB
  • Processor cache typeSmart Cache
  • Processor base power15 W
  • Maximum turbo power57 W

Neural processor unit (NPU)

  • Neural processor unit (NPU)Intel AI Boost
  • Maximum frequency NPU1.4 GHz
  • Sparsity supportYes
  • Windows Studio effects supportYes
  • AI datatype support on NPUFP16, FP32, Int8
  • AI software frameworks supported by NPUDirectML, ONNX RT, OpenVINO, Windows ML

Memory

  • Internal memory32 GB
  • Internal memory typeLPDDR5x-SDRAM
  • Memory clock speed6400 MHz
  • Memory form factorOn-board
  • Maximum internal memory32 GB
  • Memory channelsDual-channel

Storage

  • Total storage capacity1 TB
  • Storage mediaSSD
  • Total SSDs capacity1 TB
  • Number of SSDs installed1
  • SSD capacity1 TB
  • SSD interfacePCI Express 4.0
  • NVMeYes
  • SSD form factorM.2
  • Optical drive typeNo
  • Card reader integratedNo

Graphics

  • Discrete graphics card modelNot available
  • On-board graphics cardYes
  • On-board GPU manufacturerIntel
  • Discrete graphics cardNo
  • On-board graphics card modelIntel® Graphics

Audio

  • Audio chipRealtek ALC3306
  • Audio systemDolby Atmos
  • Number of built-in speakers2
  • Speaker power2 W
  • Built-in microphoneYes
  • Number of microphones2

Camera

  • Front cameraYes
  • Front camera resolution1920 x 1080 pixels
  • Front camera HD typeFull HD
  • Infrared (IR) cameraYes
  • Privacy cameraYes
  • Privacy typePrivacy shutter

Network

  • Top Wi-Fi standardWi-Fi 6E (802.11ax)
  • Wi-Fi standardsWi-Fi 6E (802.11ax)
  • Mobile network connectionNo
  • Antenna type2x2
  • WLAN controller modelIntel Wi-Fi 6E AX211
  • WLAN controller manufacturerIntel
  • Ethernet LANNo
  • BluetoothYes
  • Bluetooth version5.3

Ports & interfaces

  • USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
  • HDMI ports quantity1
  • HDMI version2.1
  • Thunderbolt 4 ports quantity2
  • Intel® Thunderbolt 4Yes
  • Combo headphone/mic portYes
  • USB Type-C DisplayPort Alternate ModeYes
  • USB Sleep-and-ChargeYes
  • USB Sleep-and-Charge ports1

Performance

  • Motherboard chipsetIntel SoC

Keyboard

  • Pointing deviceThinkPad UltraNav
  • Numeric keypadNo
  • Keyboard backlitYes
  • Spill-resistant keyboardYes
  • Keyboard languageUS English

Software

  • Operating system architecture64-bit
  • Operating system installedWindows 11 Pro

Battery

  • Battery technologyLithium Polymer (LiPo)
  • Battery capacity57 Wh

Power

  • USB Power Delivery (USB PD)Yes

Security

  • Cable lock slotYes
  • Cable lock slot typeKensington
  • Fingerprint readerYes
  • Smart card readerNo
  • Trusted Platform Module (TPM)Yes
  • Trusted Platform Module (TPM) version2.0
  • Password protectionYes
  • Password protection typeBIOS, Power on, Supervisor, SSD

Operational conditions

  • Operating temperature (T-T)5 - 35 °C
  • Storage temperature (T-T)5 - 43 °C
  • Operating relative humidity (H-H)8 - 95%
  • Storage relative humidity (H-H)5 - 95%
  • Maximum shipping altitude3048 m

Certificates

  • Compliance certificatesRoHS
  • CertificationMIL-STD-810H military test passed

Sustainability

  • Sustainability certificatesTCO, ENERGY STAR, EPEAT Gold, ErP

Weight & dimensions

  • Width312.8 mm
  • Depth214.8 mm
  • Height15 mm
  • Weight1.08 kg

Product Identifiers

  • Manufacturer Part No (MPN)21KC000MUS
  • Barcode (EAN)197530074561
