ASUS
S5506MA-MA006W
125HCPU
Intel Arc GraphicsGPU
N/AVALUE SCORE
16 GBRAM
1 TBSTORAGE
15.6" DISPLAY
All Prices (1)
Refurbished - ASUS Vivobook S 15 OLED S5506MA Intel Core Ultra 5 125H 16GB RAM 1TB SSD 15.6" Windows 11 Home Laptop
£699.99
Go to Store Price History
Not enough historical data yet.
Technical Specifications
Design
- Colour nameMist Blue
- Product typeLaptop
- Product colourBlue
- Form factorClamshell
- Market positioningHome
Display
- Display diagonal39.6 cm (15.6")
- Display resolution2880 x 1620 pixels
- TouchscreenNo
- HD type3K
- Panel typeOLED
- Native aspect ratio16:9
- Display surfaceGloss
- Display brightness400 cd/m²
- Maximum display brightness (HDR)600 cd/m²
- RGB colour spaceDCI-P3
- Colour gamut100%
- Maximum refresh rate120 Hz
- Contrast ratio (typical)1000000:1
- High Dynamic Range (HDR) supportedYes
- High Dynamic Range (HDR) technologyDisplayHDR True Black 500
Processor
- Processor manufacturerIntel
- Processor familyIntel Core Ultra 5
- Processor generationIntel® Core™ Ultra (Series 1)
- Processor model125H
- Processor cores14
- Processor threads18
- Processor boost frequency4.5 GHz
- Performance cores4
- Efficient cores8
- Low Power Efficient-cores2
- Performance-core Max Turbo Frequency4.5 GHz
- Efficient-core Max Turbo Frequency3.6 GHz
- Low Power Efficient-core Max Turbo Frequency2.5 GHz
- Performance-core base frequency1.2 GHz
- Efficient-core base frequency0.7 GHz
- Low Power Efficient-core Base Frequency700 MHz
- Processor cache18 MB
- Processor cache typeSmart Cache
- Processor base power28 W
- Maximum turbo power115 W
Neural processor unit (NPU)
- Neural processor unit (NPU)Intel AI Boost
- Maximum frequency NPU1.4 GHz
- Sparsity supportYes
- Windows Studio effects supportYes
- AI software frameworks supported by NPUDirectML, ONNX RT, OpenVINO, Windows ML
Memory
- Internal memory16 GB
- Internal memory typeLPDDR5x-SDRAM
- Memory form factorOn-board
- Maximum internal memory16 GB
Storage
- Total storage capacity1 TB
- Storage mediaSSD
- Total SSDs capacity1 TB
- Number of SSDs installed1
- SSD capacity1 TB
- SSD interfacePCI Express 4.0
- NVMeYes
- SSD form factorM.2
- Optical drive typeNo
- Card reader integratedYes
- Compatible memory cardsMicroSD (TransFlash)
Graphics
- Discrete graphics card modelNot available
- On-board graphics cardYes
- On-board GPU manufacturerIntel
- Discrete graphics cardNo
- On-board graphics card familyIntel Arc Graphics
- On-board graphics card modelIntel Arc Graphics
Audio
- Audio systemSmart Amp
- Speakers manufacturerHarman Kardon
- Built-in microphoneYes
Camera
- Front cameraYes
- Front camera resolution1920 x 1080 pixels
- Front camera HD typeFull HD
- Infrared (IR) cameraYes
- Privacy cameraYes
- Privacy typePrivacy shutter
Network
- Top Wi-Fi standardWi-Fi 6E (802.11ax)
- Wi-Fi standardsWi-Fi 6E (802.11ax)
- Mobile network connectionNo
- Antenna type2x2
- Ethernet LANNo
- BluetoothYes
- Bluetooth version5.3
Ports & interfaces
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
- HDMI ports quantity1
- HDMI version2.1
- Thunderbolt 4 ports quantity2
- Intel® Thunderbolt 4Yes
- Combo headphone/mic portYes
- USB Type-C DisplayPort Alternate ModeYes
Performance
- Repairability index8.6
Keyboard
- Pointing deviceTouchpad
- Numeric keypadYes
- Keyboard backlitYes
- Keyboard backlit colourRGB
- Keyboard backlit zone1-zone RGB
Software
- Operating system architecture64-bit
- Operating system installedWindows 11 Home
Battery
- Battery technologyLithium-Ion (Li-Ion)
- Number of battery cells4
- Battery capacity75 Wh
Power
- AC adapter power90 W
- AC adapter frequency50 - 60 Hz
- AC adapter input voltage100 - 240 V
- AC adapter output current4.5 A
- AC adapter output voltage20 V
- USB Type-C charging portYes
- USB Power Delivery (USB PD)Yes
Security
- Windows HelloYes
- Trusted Platform Module (TPM)Yes
- Password protectionYes
- Password protection typeBIOS, User
Weight & dimensions
- Width353.6 mm
- Depth246.9 mm
- Height (front)1.39 cm
- Height (rear)1.59 cm
- Weight1.5 kg
Packaging content
- AC adapter includedYes
Product Identifiers
- Manufacturer Part No (MPN)RFB-S5506MA-MA006W
- Barcode (EAN)4711387641309
