Acer
PHN16S-71-98RF
16" Display
Intel Core Ultra 9 275HXScore: 55.840CPU
32 GBRAM
1 TBStorage
NVIDIA GeForce RTX 5070 TiGraphics
Price History
Not enough historical data yet.
Technical Specifications
Design
- Product typeLaptop
- Product colourBlack
- Form factorClamshell
- Market positioningGaming
Display
- Display diagonal40.6 cm (16")
- Display resolution2560 x 1600 pixels
- TouchscreenNo
- HD typeWQXGA
- Panel typeMini LED
- Display technology marketing nameCineCrystal
- Native aspect ratio16:10
- Maximum refresh rate165 Hz
Processor
- Processor manufacturerIntel
- Processor familyIntel Core Ultra 9
- Processor generationIntel Core Ultra (Series 2)
- Processor model275HX
- Processor cores24
- Processor threads24
- Processor boost frequency5.4 GHz
- Performance cores8
- Efficient cores16
- Performance-core Max Turbo Frequency5.4 GHz
- Efficient-core Max Turbo Frequency4.6 GHz
- Performance-core base frequency2.7 GHz
- Efficient-core base frequency2.1 GHz
- Processor cache36 MB
- Processor base power55 W
- Maximum turbo power160 W
Neural processor unit (NPU)
- Neural processor unit (NPU)Intel AI Boost
- Sparsity supportYes
- Windows Studio effects supportYes
- AI software frameworks supported by NPUDirectML, OpenVINO, Windows ML, ONNX RT, WebNN
- Total processor performance up to36 TOPs
- NPU performance up to13 TOPs
- GPU performance up to8 TOPs
Memory
- Internal memory32 GB
- Internal memory typeDDR5-SDRAM
- Memory form factorSO-DIMM
- Memory slots2x SO-DIMM
- Maximum internal memory64 GB
Storage
- Total storage capacity1 TB
- Storage mediaSSD
- Total SSDs capacity1 TB
- Number of SSDs installed1
- SSD capacity1 TB
- SSD interfacePCI Express 4.0
- NVMeYes
- SSD form factorM.2
- Optical drive typeNo
- Card reader integratedYes
- Compatible memory cardsMicroSD (TransFlash)
Graphics
- Discrete GPU manufacturerNVIDIA
- Discrete graphics card modelNVIDIA GeForce RTX 5070 Ti
- Discrete graphics card memory12 GB
- Discrete graphics memory typeGDDR7
- On-board graphics cardYes
- On-board GPU manufacturerIntel
- Discrete graphics cardYes
- On-board graphics card familyIntel® Graphics
- On-board graphics card modelIntel® Graphics
Audio
- Audio systemDTS:X Ultra
- Number of built-in speakers2
- Built-in microphoneYes
- Number of microphones3
Camera
- Front cameraYes
- Front camera resolution1920 x 1080 pixels
- Front camera HD typeFull HD
Network
- Top Wi-Fi standardWi-Fi 6E (802.11ax)
- Wi-Fi standardsWi-Fi 6E (802.11ax)
- Mobile network connectionNo
- Antenna type2x2
- WLAN controller modelKiller Wi-Fi 6E 1675i
- Ethernet LANYes
- Ethernet LAN data rates5000 Mbit/s
- BluetoothYes
Ports & interfaces
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity2
- Ethernet LAN (RJ-45) ports1
- HDMI ports quantity1
- Intel® Thunderbolt 4Yes
- Combo headphone/mic portYes
- USB Type-C DisplayPort Alternate ModeYes
Keyboard
- Pointing deviceTouchpad
- Numeric keypadYes
- Keyboard backlitYes
- Keyboard backlit colourRGB
- Keyboard backlit zone4-zone RGB
- Keyboard languageGerman
Software
- Operating system architecture64-bit
- Operating system installedWindows 11 Home
Battery
- Battery technologyLithium-Ion (Li-Ion)
- Number of battery cells4
- Battery capacity76 Wh
Power
- AC adapter power230 W
- USB Type-C charging portYes
Weight & dimensions
- Width356.8 mm
- Depth275.5 mm
- Height19.9 mm
- Weight2.3 kg
Packaging content
- AC adapter includedYes
Product Identifiers
- Manufacturer Part No (MPN)PHN16S-71-98RF
- Barcode (EAN)195133285117
